Rain Bird 3500 Series Rotor Sprinkler | 32SA | W32001 | 3504PC | Y34000

Click image to enlarge

3504 Modell with 6 nozzles - 4" Pop-Up (10 cm)
RBR--3504
Quantity x

The 3500 Series Rotor is an easy to use short to mid-range 1/2" gear-drive rotor, offering value and convenience for residential applications. Utilizing a simple flat-bladed screwdriver, the 3500's arc adjustment is quick and easy.

This versatile rotor offers an attachable nozzle tree with six superior performing Rain Curtain nozzles and the convenience of reversing full and part circle operation (up to 360 degrees) in one unit. Plus, a nozzle removal feature and easily removable filter screen makes maintenance a breeze. All of this, an affordable price and a 3-year factory warranty makes the 3500 Series one rotor that is easy to use, easy to buy and tough to beat!

The Rain Bird 3500 professional series is compatible with the economy 32SA model.

Note on the 32SA model: The 32SA model has only one 3 GPM nozzle when purchased. Which is not recommended because this nozzle consumes too much water. In addition, the nozzles must be purchased separately. That's what the big box store doesn't tell you!

Here for less or equal price, you have the 3500 professional series including all the nozzles!

FEATURES & BENEFITS

  • Top-adjust arc adjustment requiring only a flat-blade screwdriver.
  • Shrub and 4" models available.
  • True 4" (10 cm) pop-up (measured from center of nozzle).
  • 40- 360° Arc Part-Circle arc rotation and reversing Full-Circle rotation in one.
  • Attachable nozzle tree of six Rain Curtain™ nozzles.
  • Radius adjustment screw allows up to 35% radius reduction without changing nozzles.
  • Quick Check Arc/Fast Forward.
  • Dual action, positive stop wiper seal protects internals from debris and assures positive pop-up and retraction.
  • Self-adjusting stator does not require replacement when changing nozzles.
  • Water-lubricated gear-drive design for durable, reliable operation.
  • Easily removable filter screen.
  • Nozzle removal feature.
  • Arc setting factory preset at 180° for installation convenience.

OPERATION RANGE

  • Radius: 15' to 35’ (4,6 to 10,7 m)
  • Radius may be reduced up to 35% with radius reduction screw
  • Pressure 25-55 psi (1,7 to 3,8 Bars)
  • Flow rate: 0.54 to 4.6 GPM (2,0 à 14,4 l/m)

SPECIFICATIONS

  • 1/2" FNPT bottom inlet
  • Six standard angle nozzles

DIMENSIONS

  • Overall Height: 7" (17,8 cm)
  • Exposed surface diameter: 1.16" (2,9 cm)
  • Popup Height: 4" (10 cm)

Three-year trade warranty.
